RIEGLER Captive swivel safety coupling I.D. 6, ISO 6150 C, G 1/2 IT, gray

Price:

36.09 €
    ​
English (US)
  2. Shop
  3. Non-Interchangeable Quick-Lock Couplings
  4. RIEGLER Captive swivel safety coupling I.D. 6, ISO 6150 C, G 1/2 IT, gray
RIEGLER Captive swivel safety coupl. I.D. 6, ISO 6150 C, G 1/2 IT, yellow
RIEGLER Captive swivel safety coupl. I.D. 6, ISO 6150 C, G 1/2 IT, yellow
36.09 €
36.09 €
RIEGLER Captive swivel safety coupling I.D. 6, ISO 6150 C, G 1/2 IT, red
RIEGLER Captive swivel safety coupling I.D. 6, ISO 6150 C, G 1/2 IT, red
36.09 €
36.09 €

RIEGLER Captive swivel safety coupling I.D. 6, ISO 6150 C, G 1/2 IT, gray

https://www.filcom-technik.de/web/image/product.template/211247/image_1920?unique=a82012f

Type number: 426.03-DREH-GR

EAN: 4047322564939

36.09 € 36.09 EUR 36.09 € VAT Included

46.66 € VAT Included

    This combination does not exist.

    from 110 € free shipping Details shipping costs
    Contact Us
    Product no. :
    141874
    Category :
    Non-Interchangeable Quick-Lock Couplings
    Weight :
    0.14 kg

    Unverwechselbare Dreh-Sicherheitskupplung NW 6, ISO 6150 C, Stahl, 2-stufig, G 1/2 IG, grau, max. 25 bar, Temp. -15 °C bis 200 °C

    Temperature range min. -15 °C
    Temperature range max. 200 °C
    Housing Steel, QPQ treated
    Sealing material FKM
    Flow rate measurement at 6 bar and Î"<sub>p </sub>= 0.5 bar
    Flow rate 630 l/min (air)
    Spring Stainless steel
    Sleeve Galvanized steel, painted in colour
    Threaded piece Galvanized steel
    Valve Polyphenylensulfid (PPS)
    Operating pressure max. 25 bar / max. 16 bar when engaging/disengaging
    SW 24 mm
    Colour grau
    NW 6
    Length 67 mm
    Connection G 1/2 IG
    Connector profile gemäß ISO 6150 C
    Class name PLUS
