RIEGLER Captive swivel safety coupling I.D. 6, ISO 6150 C, G 1/4 IT, gray
Type number: 426.01-DREH-GR
EAN: 4047322566230
Unverwechselbare Dreh-Sicherheitskupplung NW 6, ISO 6150 C, Stahl, 2-stufig, G 1/4 IG, grau, max. 25 bar, Temp. -15 °C bis 200 °C
| Temperature range min. | -15 °C |
| Temperature range max. | 200 °C |
| Housing | Steel, QPQ treated |
| Sealing material | FKM |
| Flow rate measurement | at 6 bar and Î"<sub>p </sub>= 0.5 bar |
| Flow rate | 630 l/min (air) |
| Spring | Stainless steel |
| Sleeve | Galvanized steel, painted in colour |
| Threaded piece | Galvanized steel |
| Valve | Polyphenylensulfid (PPS) |
| Operating pressure | max. 25 bar / max. 16 bar when engaging/disengaging |
| SW | 22 mm |
| Colour | grau |
| NW | 6 |
| Length | 56 mm |
| Connection | G 1/4 FEMALE THREAD |
| Connector profile | gemäß ISO 6150 C |
| Class name | PLUS |
