RIEGLER Pressure gauge, CrNi steel, rear eccentric, G 1/2, 0-4 bar, Ø 100
Typennummer: 4092
EAN: 4047322084949
Manometer in CrNi-Stahl-Ausführung, Anschluss hinten exzentrisch, G 1/2, Typ 232.50, Güteklasse 1,0, Messber. 0 - 4,0 bar, Ø 100
| Medium temperature min. | -40 °C |
| Medium temperature max. | 200 °C |
| Ambient temperature min. | -40 °C |
| Ambient temperature max. | 60 °C |
| Material | CrNi steel |
| Type | 232.50 |
| Viewing window | Mehrschichten-Sicherheitsglas |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 4 |
| Diameter | 100 mm |
| Graduation value in the bar range | 0.1 bar |
| Connection | G 1/2 |
| Quality class | 1 |
| Lower / Upper measuring range limit | Überdruck |
| Connection position | rear, eccentric |
| Class name | STAINLESS STEEL |
| Process connection material | CrNi steel |
