2/2-way solenoid valve NO, directly operated, 24 V DC
Typennummer: MV 1534 ES
EAN: 4047322324144
2/2-Wege-Magnetventil, Edelstahl, NO, direktgesteuert, 24 V DC, Mediumstemp. max. 80 °C / 90 °C, G 1/2, PN 0 - 7 bar
| Housing | Edelstahl 1.4301 |
| Sealing material | FPM |
| Protection class | IP 65 |
| Operating pressure min. | 0 bar |
| Max. operating pressure | 7 bar |
| Interior parts | Edelstahl |
| Valve seat | Edelstahl 1.4301 |
| Thread | G 1/2 |
| Thread standard | G-Gewinde nach DIN EN ISO 228-1 |
| NW | 5 |
| Design | 2 |
| A | 85 mm |
| B | 52 mm |
| C | 92 mm |
| Class name | EDELSTAHL |
