RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-600bar/8500 psi
Type number: 816-CDE
EAN: 4047322177252
Glyzerinmano. »pressure line«, CrNi-Stahl-Gehäuse, Anschluss hinten zentr., G 1/4, Gütekl. 1,6, Messber. 0-600,0 bar/8500 psi, Ø63
| Housing | Stainless steel 1.4301 |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Brass |
| Pointer movement | Messing |
| Viewing window | Glas |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 600 |
| Diameter | 63 mm |
| Graduation value in the bar range | 20 bar |
| Execution | Bourdon tube pressure gauge with glycerine filling |
| Connection | G 1/4 |
| Quality class | 45444 |
| Connection position | rear, centric |
| Class name | EASY |
| Process connection material | Copper alloy |
