RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0 - 6 bar/85 psi
Type number: 706-CDE
EAN: 4047322176217
Glyzerinmano. »pressure line«, CrNi-Stahl-Gehäuse, Anschluss radial unten, G 1/4, Gütekl. 1,6, Messber. 0 - 6,0 bar/85 psi, Ø 63
| Housing | Stainless steel 1.4301 |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Brass |
| Pointer movement | Messing |
| Viewing window | Glas |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 6 |
| Diameter | 63 mm |
| Graduation value in the bar range | 0.2 bar |
| Execution | Bourdon tube pressure gauge with glycerine filling |
| Connection | G 1/4 |
| Quality class | 45444 |
| Connection position | radial bottom |
| Class name | EASY |
| Process connection material | Copper alloy |
