RIEGLER Standard pressure gauge »pressure line« G 1/4, 0 - 1 bar/14.5 psi
Type number: 101-KDE
EAN: 4047322175524
Standardmano. »pressure line«, Kunststoffgeh., Anschluss radial unten, G 1/4, Güteklasse 2,5, Messber. 0 - 1,0 bar/14,5 psi, Ø 50
| Housing | Plastic |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Copper alloy |
| Pointer movement | Kupferlegierung |
| Viewing window | Kunststoff |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 1 |
| Diameter | 50 mm |
| Graduation value in the bar range | 0.05 bar |
| Execution | Bourdon tube pressure gauge |
| Connection | G 1/4 |
| Quality class | 45414 |
| Lower / Upper measuring range limit | Überdruck |
| Connection position | radial bottom |
| Class name | EASY |
| Process connection material | Copper alloy |
