RIEGLER Safety jaw coupling, I.D. 13 (1/2"), with safety collar
Type number: KT 13 SBS
EAN: 4047322260152
Sicherheits-Klauenkupplung mit Schlauchanschluss, LW 13 (1/2"), Sicherungsbund, Temperguss, PN max. 16 bar, Temp. -40 °C bis 95 °C
| Sealing material | NBR |
| Max. operating pressure | 16 bar |
| Material | Malleable iron |
| Operating temperature min. | -40 °C |
| Operating temperature max. | 95 °C |
| Claw distance | 42 mm |
| DN | 10 |
| for inner hose Ø | 13 (1/2") |
| Safety collar | 24 |
| L | 97.7 mm |
| H | 63 mm |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Theme shop | SAFETY |
| Class name | FLEX |
