RIEGLER Micrometre pressure gauge, radial bottom G 1/2, -1/+1.5 bar, Ø160
Typennummer: 1158/2
EAN: 4047322020961
Feinmessmanometer, Anschluss radial unten, G 1/2, Typ 312.20, Güteklasse 0,6, Skaleneinteil. 0,020, Messber. -1 / +1,5 bar, Ø 160
| Housing | CrNi steel |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 80 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Type | 312.20 |
| Measuring element | Copper alloy |
| Pointer movement | Kupferlegierung |
| Viewing window | Instrumentenflachglas |
| Measuring range min. bar | -1 |
| Measuring range max. bar | 1.5 |
| Diameter | 160 mm |
| Graduation value in the bar range | 0.02 bar |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| Connection | G 1/2 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW614N |
| Quality class | 0.6 |
| Lower / Upper measuring range limit | Vakuum/Überdruck |
| Ring | CrNi steel |
| Connection position | radial bottom |
| Class name | MAX |
| Process connection material | Copper alloy |
