RIEGLER Glycerine pressure gauge, triangle front ring, G 1/2, 0 - 25 bar
Typennummer: 1028
EAN: 4047322012263
Glyzerinmano. mit Bügelbef. und Dreikantfrontring, Anschluss hinten exzentrisch, G 1/2, Gütekl. 1,0, Messber. 0 - 25,0 bar, Ø 100
| Housing | Pressed brass |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Type | 213.40 |
| Measuring element | Copper alloy |
| Pointer movement | Kupferlegierung |
| Viewing window | Acrylglas |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 25 |
| Diameter | 100 mm |
| Graduation value in the bar range | 0.5 bar |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| Connection | G 1/2 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Quality class | 1 |
| Lower / Upper measuring range limit | Überdruck |
| Connection position | rear, eccentric |
| Class name | MAX |
| Process connection material | Copper alloy |
