RIEGLER High pressure regulator 60 bar, G 3/8, Control range 1 - 20 bar
Type number: 637.902
EAN: 4047322270038
Hochdruckregler 60 bar, inkl. Mano., G 3/8, Regelbereich 1 - 20 bar, Eingangsdruck max. 60 bar, Betriebstemp. -10 °C bis 90 °C
| Inlet pressure max. | 60 bar |
| Housing | Brass |
| Sealing material | NBR |
| Flow rate measurement | at P<sub>1</sub> = 20 bar, P<sub>2</sub> = 10 bar and pressure drop ˆ†<sub>p</sub> = 4 bar |
| Area of application | Compressed air and other neutral, non-flammable gases |
| Operating temperature min. | -10 °C |
| Operating temperature max. | 90 °C |
| Thread | G 3/8 |
| Flow rate | 2500 l/min |
| Control range min. | 1 bar |
| Control range max. | 20 bar |
| A | 72 mm |
| B | 164 mm |
| C | 31 mm |
| D | 133 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | none |
| Class name | FLEX |
