RIEGLER Special filter »Standard« Metal container, 0.01 µm, Size 4, G 1
Typennummer: 696 M
EAN: 4047322113472
Spezialfilter »Standard« mit Metallbehälter, 0,01 µm, BG 4, G 1, PE max. 25 bar, Med.-Umgebungstemp. max. 90 °C, Ablass: manuell
| Inlet pressure max. | 25 bar |
| Housing | Die-cast zinc, painted silver |
| Flow rate measurement | at P<sub>2</sub> = 6 bar and pressure drop Î"<sub>p</sub> = 1 bar |
| Series | Standard |
| Container | Metal container |
| Filter fineness | 0.01 µm |
| Medium temperature min. | 0 °C |
| Medium temperature max. | 90 °C |
| Ambient temperature min. | 0 °C |
| Ambient temperature max. | 90 °C |
| Efficiency | 999.99 |
| Thread | G 1 |
| Flow rate | 7000 l/min |
| Condensate drain | manually |
| DN | 25 |
| BG | 4 |
| A | 133 mm |
| C | 36 mm |
| D | 206 mm |
| H | 120 mm |
| Class name | EASY |
