RIEGLER Check valve »multifix«, Size 3, G 3/4
Typennummer: V 34/1
EAN: 4047322167673
Rückschlagventil »multifix«, BG 3, G 3/4, Öffnungsdruck min. 0,1 bar, Eingangsdruck max. 16 bar, Mediums-Umgebungstemp. max. 60 °C
| Inlet pressure max. | 16 bar |
| Housing | Zinc die casting |
| Sealing material | NBR |
| Flow rate measurement | at P<sub>1</sub> = 6 bar and pressure drop Î"<sub>p</sub> = 1 bar |
| Series | multifix |
| Medium temperature min. | -10 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -10 °C |
| Ambient temperature max. | 60 °C |
| Opening pressure min. | 0.1 bar |
| Thread | G 3/4 |
| Flow rate | 6000 l/min |
| BG | 3 |
| A | 68.8 mm |
| B | 67 mm |
| C | 33.5 mm |
| D | 33.5 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | none |
| Class name | PLUS |
