RIEGLER Mist oiler »multifix-mini« Metal container, metal drip cap, G 1/4
Typennummer: L 06 M
EAN: 4047322155649
Nebelöler »multifix-mini« mit Metallbehälter und Tropfaufsatz Metall, BG 0, G 1/4, PE max. 20 bar, Med.-Umgebungstemp. max. 60 °C
| Inlet pressure max. | 20 bar |
| Housing | Zinc die casting |
| Sealing material | NBR |
| Flow rate measurement | at P<sub>2</sub> = 6 bar and pressure drop Î"<sub>p</sub> = 1 bar |
| Series | multifix-mini |
| Container | Metal container |
| Dropper attachment | Zink-Glas-NBR |
| Oil grade | CL 32 according to DIN 51517-ISO VG 32 |
| Medium temperature min. | -10 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -10 °C |
| Ambient temperature max. | 60 °C |
| Thread | G 1/4 |
| Flow rate | 1150 l/min |
| DN | 5 |
| BG | 0 |
| A | 40 mm |
| B | 147.6 mm |
| C | 62.6 mm |
| D | 85 mm |
| Class name | PLUS |
