Filtration Group Double return filter PI 51010-058 NBR
Double return line filter Pi 51 DIN 2455 switchable
Nominal size 1 l/min,
including:
- Bypass 3.5 bar
- Electrical maintenance indicator 2.2 bar
Filtration Group's filtration and separation solutions ensure success, guarantee trouble-free plant operation, promote clean working environments and protect valuable capital goods
Filtration Group (formerly MAHLE) Double return line filter Pi 511-58 switchable / 7799336
Intended for mounting on containers
Modular system for optimum filter selection
Low space requirement due to compact design
Minimal pressure loss due to streamlined design of the components
Bypass 3.5 bar
Electrical maintenance indicator 2.2 bar
Version with threaded and flanged connections
Equipped with highly efficient PS filter elements
Guaranteed separation rates according to multi-pass test in accordance with ISO 16889
High differential pressure stability and dirt holding capacity of the elements
Important note:
We supply the Mahle Pi 511-58 double return line filter without the filter elements.
For suitable filter elements and accessories, see "Accessories".
| Connection type | Thread ISO 228 |
| Connection size | G 1 |
| Display pressure of contamination indicator (bar) | 2,2 |
| Evaluation of pollution indicators | electrical / mechanical |
| Operating temperature | -10°C bis +80°C |
| Bypass opening pressure (bar) | 3,5 |
| Contact type Contamination indicator | Closer / Opener |
| Max. Operating pressure (bar) | 10 |
| Nominal size | 100 |
| Type Contamination indicator | Contamination indicator |
| Contamination indicator | ja |
| Seal material | NBR |
| Filter housing material | Kunststoff |
| Filter head material | GD AI |
