RIEGLER Diaphragm pressure gauge, Robust design, G 1/2, 0-1.6 bar, Ø 100
Type number: PL 1912
EAN: 4047322163279
Plattenfedermanometer, Robustausführung, Anschluss radial unten, G 1/2, Typ 422.12, Güteklasse 1,6, Messber. 0 - 1,6 bar, Ø 100
| Housing | Gray cast iron, black |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 100 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Type | 422.12 |
| Measuring element | CrNi steel |
| Pointer movement | Kupferlegierung |
| Viewing window | Instrumentenflachglas |
| Measuring flange diameter | 100 mm |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 1.6 |
| Diameter | 100 mm |
| Graduation value in the bar range | 0.05 bar |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| Connection | G 1/2 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Quality class | 45444 |
| Lower / Upper measuring range limit | Überdruck |
| Ring | Stainless steel, black |
| Connection position | radial bottom |
| Class name | FLEX |
| Process connection material | Steel |
