KAESER Screw compressor model SM 10-8 T SC2 OAL
Der KAESER Schraubenkompressor SM mit SIGMA PROFIL, Kompressorsteuerung SIGMA CONTROL 2 und Kältetrockner
Volumenstrom bei Überdruck: 0,94 l/min | Höchstüberdruck: 8 bar | Nennleistung Antriebsmotor: 5,5 KW | Elektrischer Anschluss: 400 V / 3 Ph / 50 Hz
KAESER Kompressoren SE
KAESER COMPRESSORS, a family-owned company, is one of the world's leading manufacturers and providers of products and services in the field of compressed air. Founded in 1919 as a machine workshop, Kaeser now operates at two production sites in Germany and employs approximately 7,500 people worldwide.
Product no. :
101736.0Category :
With Refrigeration DryerWeight :
295.00 kgDelivery area :
Germany| Max. Overpressure (bar) | 8 |
| Volume flow at overpressure (m³/min) | 0,94 |
| Rated power drive motor (kW) | 5,5 |
| Drive motor efficiency class | IE3 |
| Permissible pressure loss cooling channel (Pa) | 30 |
| Max. usable warm air volume (m³/h) | 2.100 |
| Max. usable heat output "warm air" (kW) | 6,8 |
| Max. usable heat output "warm water" (kW) | 4,5 |
| Required supply air opening (m2) | 0,25 |
| Drive motor protection class | IP 55 |
| Electrical supply | 400 V / 3 Ph / 50 Hz |
| Full load current | 14 A |
| Fuse: Max current | 20 A |
| Cooling fluid filling quantity (litres) | 4 |
| Width (mm) | 630 |
| Depth (mm) | 1.090 |
| Height (mm) | 1.100 |
| Weight (kg) | 295 |
| Compressed air connection | G 3/4 |
| Sound pressure level (dbA) | 62 |
| Refrigeration dryer power consumption (kW) | 0,49 |
| Refrigeration dryer pressure dew point (°C) | 3 |
| Refrigeration dryer pressure loss (bar) | 0,10 |
| Refrigerant | R-513A |
| Refrigerant charge (kg) | 0,39 |
| CO2 equivalent (tonnes) | 0,25 |
| Global warming potential GWP | 631 |
